PANASONIC PT-MZ682 WUXGA LCD Laser Projector (6,500 lumens) Optional Lenses

The PT-MZ882 Series’s sustainability story begins before you take delivery. In addition to using responsibly procured materials, the main projector body contains about 10%¹ recycled resins, reducing the utilization of virgin materials. By supporting eco-friendly manufacturing processes and pursuing recycling-based programs at end-of-life, your organization helps minimize environmental impact during operation and throughout the product’s lifecycle.

1 By weight of the total weight of plastic parts in the projector main unit. Excludes projection lenses, printed circuit boards, labels, cables, connectors, electronic components, optical components, ESD components, EMI component adhesives, and coatings.

Refinements to the optical engine yield higher brightness over every model in the previous series while significantly enhancing energy efficiency. The PT-MZ882, for example, produces 8,200 lm¹ with a max. consumption of 465 W compared to 8,000 lm¹ at 490 W for the previous PT-MZ880 model, achieving a rating of 17.6 lm/W and an 8% efficiency improvement. Save on energy costs and reduce the carbon footprint of every unit in your fleet.

Note: Maximum consumption value in NORMAL Mode on AC 100–120 V power.

1 Measurement, measuring conditions, and notation methods comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.

Like your PC, Panasonic projectors “sleep” after a certain idle period and shut down when this Quick Startup period expires to save energy. If playback resumes after the Quick Startup period elapses, you must manually power on the projector again. To avoid this, some users disable the Quick Startup timer or keep the projector running with the shutter on, wasting energy. PT-MZ882 Series solves the issue with Auto Power On. This new function powers the projector on and resumes playback automatically when an input signal is detected, even if the unit is shut down. Presenters can pause and resume their program without significant interruption, and administrators reap energy savings across their schools or businesses.

Note: Settings cannot be made in the following cases: When [STANDBY MODE] is set to [ECO] or when [IN STANDBY MODE] is set to [ON] in the [AUDIO SETTINGS] menu. Auto Power On is supported when the input signal is transmitted via HDMI™ or COMPUTER IN terminals.

ECO Filter includes a Micro-Cut Filter that collects minute dust particles with an electrostatic effect. With the dust-resistant projector cabinet design, ECO Filter enables low maintenance and long-term use with less downtime. Filter replacement is recommended at 20,000 hours¹ when used in typical office and classroom environments. If it’s necessary to maintain the filter before then, it can be washed and reused up to two times², reducing wastage, cost, and labor.

1 Filter replacement cycles (measured values) are shown for environments with 0.15 mg/m³ of airborne particulate matter. The filter replacement cycle varies depending on the usage conditions and usage environment.

2 When washing the filter with water, please follow the procedures listed in the operating instructions. Replacement is recommended after it has been washed and reused twice or if it is not sufficiently clean after washing.

Multi-Laser Drive Engine ensures stable projection in the unlikely event that light-source problems occur. PT-MZ882 Series is equipped with multiple modules consisting of many laser diodes. If one of the elements malfunctions, Failover Circuitry is activated so that projection can continue with minimal brightness reduction. This gives your presenters the confidence to work without fear of equipment failure in the middle of a presentation.

Input signals are analyzed frame by frame to regulate light output for the best contrast performance in every scene. In addition to accurately reproducing complex images that contain a mix of dark and bright hues, Dynamic Contrast is more energy efficient than previous technologies. The projector’s high 3,000,000:1¹ contrast ratio enhances detail definition in shadows with deeper blacks, brighter whites, and more natural skin tones for an improved sense of depth and definition.

1 Full On/Full Off, when [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1] or [2]. Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped.

Daylight View Basic is a dynamic adjustment technology that enhances image sharpness by clarifying detail definition in dark areas of the picture, which can be difficult to see in bright light. A sensor measures the ambient light in the room and optimizes sharpness, halftone color, contrast, and brightness for best results according to the room’s illumination.

Unique image correction circuitry reproduces details more clearly and sharply. It analyzes video signal frequencies in each scene and adjusts for optimal sharpness based on information extracted from the signal. Compared to conventional image processing technology, this system reproduces images with an even more natural and dimensional feel and also works to sharpen text edges for more comfortable legibility.

With lessons, meetings, and other events often including remote participants, projector noise mustn’t distract from the presentation. Quiet projection helps people focus, whether in the room or participating remotely. PT-MZ882 Series includes a Quiet Mode enabling whisper-quiet 25 dB¹ operation, helping these stylish projectors blend unobtrusively into the background to keep attention focused on the presentation.

1 For the PT-MZ682 in QUIET Mode. Operating noise values are as follows: PT-MZ882: 34 db (NORMAL/ECO Mode), 26 dB (QUIET Mode); PT-MZ782: 32 db (NORMAL/ECO Mode), 26 dB (QUIET Mode); PT-MZ682: 32 db (NORMAL/ECO Mode), 25 dB (QUIET Mode).

PT-MZ882 Series ships with the ET-ELS20 (1.61–2.76:1) powered zoom lens and is compatible with six other optional lenses. Powered V/H lens-shift (V: ±67%, H: ±35%), zoom, and focus adjustment are supported via the remote control or Smart Projector Control app. The lineup of optional lenses includes the ET-ELU20 Ultra-Short-Throw Zoom Lens (0.330–0.353:1). This lens projects content without offset at the top and bottom of the image, making the PT-MZ882 Series a cost-effective solution for museums and Location-Based Entertainment (LBE) applications.

Note: V/H lens shift values are for the ET-ELS20 (equivalent to the supplied lens), ET-ELT22, ET-ELT23, and ET-ELW20. Other V/H lens shift values are as follows: V: ±60%, H: ±30% (ET-ELW22) and
V: ±50%, H: ±24% (ET-ELU20). The ET-ELW21 does not support lens shift. The PT-MZ882 Series does not support some Smart Projector Control App functions. Check device compatibility at the App Store or the Google Play Store.

The free Smart Projector Control app¹ simplifies projector setup and operation. You can control up to 64 projectors simultaneously and adjust settings without needing to project the OSD settings menu. You can also select test patterns, adjust lens settings via the new lens-control UI, lock brightness, and perform focus adjustment using your smartphone camera² from distances up to 30 m (98 ft)³. For more information, visit the Smart Projector Control webpage.

Note: The PT-MZ882 Series does not support some Smart Projector Control App functions.

1 Check device compatibility at the App Store or the Google Play Store.

2 Some devices do not support the projector autofocus function.

3 When projecting a 300-inch image. The maximum distance is 3 m (10 ft) for a 100-inch image.

Geometric Adjustment is a suite of built-in functions that allow installers to correct distortion when images are projected at an angle or onto curved screens and irregular shapes. Correction extends to spherical, cylindrical, and complex screen shapes without needing a connected PC. Maintain Aspect Ratio and Independent Corner Adjustment simplify correction. At the same time, the ability to save image-adjustment data is useful whenever correction settings need to be disabled and reapplied and for saving work progress as an adjustment profile is created.

Geo Pro simplifies geometric, blending, and color uniformity adjustments, streamlining your multi-screen calibration workflow. The software expands built-in geometric and multi-screen adjustment capabilities with a Free Grid function that governs 4-corner adjustment, keystone correction, curved-screen correction, and free-form image correction via a user-friendly interface. Software-based tools for multi-screen calibration include color matching, brightness control, color uniformity, black level, and input-signal adjustment.

Note: Visit PASS to register your projector and download free Geometry Manager Pro software for Windows^®. PT-MZ882 Series does not support some functions available in Geometry Manager Pro software.

Contrast Sync unifies Dynamic Contrast values among multiple projectors connected via serial in/out terminals. This function increases the uniformity of images in a multi-screen system and reduces edge-blend visibility for a seamless widescreen image. Shutter Sync, meanwhile, synchronizes shutter on/off timing for immersive fade-in/fade-out effects.

The data cloning function allows users to copy settings and save adjustment values from a main projector to sub projectors via LAN. This function reduces the time and effort required when setting up multiple projectors.

Note: The data-cloning function is supported among models in the same series with the same resolution. It excludes passwords, projector IDs, and network settings. Data can be copied to a maximum of 99 sub projectors via LAN.

PT-MZ882 Series features a gyro sensor that detects changes to the projector’s body pitch and roll angles and displays the information graphically in the OSD settings menu. Installers no longer need assistance to check the projection angle as the body is adjusted. They can view the on-screen graphic and adjust the projector angle before securing the unit.

All three HDMI™ inputs are compatible with control signals sent via a CEC-command-compatible component, giving you limited control over the projector using the compatible source device’s remote control. When connected to the projector via HDMI™, the projectors power up from Standby and commence playback automatically on command from a CEC-compatible player, such as the optional Wireless Presentation System PressIT.

1 Wireless Presentation System PressIT sold separately. Availability may vary by country or region.

Note: Depending on the connected CEC command-compatible device, the link control may not operate normally.

Share your screen wirelessly and switch presenters freely. PressIT is Panasonic’s optional Wireless Presentation System that allows easy screen sharing with the press of a button. PressIT comprises a receiver connected to the projector and transmitters connected to PCs or mobile devices. Securing power from your PT-MZ882 Series projector, which supports a 5 V/2 A power supply via DC OUT terminal, achieves a neat, stylish layout. Learn more about PressIT here or visit our Wireless Solutions webpage.

Note: Wireless Presentation System PressIT is sold separately. Availability may vary by country or region. When connecting a mobile device to a transmitter, the USB Type-C terminal must support DisplayPort™ ALT Mode and power supply function (5 V/0.9 A). PressIT app (available free from the App Store or the Google Play Store) is required when using Android™ or iOS/iPadOS devices. For more details, please refer to the operating manual.

For peace of mind, a remote control lock key feature prevents accidental button presses from disrupting presentations. Simply press to disable and reenable the remote keys.
